Challenge Titan 200BC Paper Cutter with Plexiglass Shield
Double-tap and hold to zoom.
Mouse over the image to zoom.
Click to Enlarge
Challenge

Challenge Titan 200BC Paper Cutter with Plexiglass Shield

Part Number: TITAN-200BC-PS

The Titan 200BC is a 20" programmable cutter. This hydraulic-powered, safe, productive, and durable machine fits into almost any budget.

$14,644.00 /EACH
List price: $14,644.00 /EACH
    • EACH
  • Availability: Available to Order

Features

• Hydraulic Cutting & Clamping
• Adjustable Clamp Pressure
• Cutting Area Protection - Plexiglas safety shield
• Plexiglas Rear Table Safety Cover
• Two-Hand Cut Buttons
• Light Line Cut Position Indicator
• Manually Controlled Backgauge with Lock
• Energy Efficient - Motor runs only when cutting
• Heavy Duty Casters For Portability
• Rugged Steel & Cast Iron Construction
• 12” x 19”/ 30.5 cm x 48 cm Side tables (optional)

Includes: (1) standard knife, (3) plastic cutting sticks, (1) jogging aid, (1) manual, (1) tool kit, (1) knife change safety holder assembly



Specifications

 Technical Data
Cutting Width: 20"
Back Gauge Control: Manual
Clamp Opening: 3" - 1/4"
Clamp Force: 1,250 lbs min. to 2,500 lbs max.
Minimum Cut:  1/2"
Table in Front of Knife:  16"
Table Behind Knife:  20"
Overall Width: 36"
Overall Length: 50" - 7/8"
Overall Height: 52" - 1/4"
Weight: 755 lbs
Electrical:  3/4 HP, single-phase, 60 Hz, 120V, AC



 Technical Data
Cutting Width: 20"
Back Gauge Control: Manual
Clamp Opening: 3" - 1/4"
Clamping Force: 1,250 lbs. minimum to 2,500 lbs. maximum
Minimum Cut: 1/2"
Table in Front of Knife: 16"
Table Behind Knife: 20"
Overall Width: 36"
Overall Length: 50" - 7/8"
Overall Height: 52" - 1/4"
Weight: 755 lbs.
Electrical: 3/4 HP, single-phase, 60 Hz, 120V, AC
