Proline 1001 Total & Rate Counter With Retro-Reflective Sensor

Part Number: FT-PL1001A

Know your production count at any given time of the day.  The PROLINE Total & Rate Counter is perfect for displaying Total Count and Rate on your production lines to know your production numbers real time.

Count up to 99,999,999 pieces on the bright seven-segment LED display.  Reset push button.  Includes 36" fixed range retro-reflective sensor, 3m cable, and power supply. Rate is selectable; per minute or per hour.

$349.00 /EACH
Proline 1001 Total & Rate Counter With Diffuse Sensor
EACH
Online Availability
Available to Order
Description Videos

Features

• Heavy-duty ABS enclosure

• Flanges with mounting holes

• 8-position seven-segment display

• 36" range diffuse sensor w/ 3 meter cable and power supply

• Other sensor types, cable extensions, and sensor mount are available.



Specifications

 Technical Data
Counting Options: Total Count & Rate Count
 Display: 8 rows 8 position, 7 segment
Sensor: 36" range retro-reflective sensor with 3m cable
Dimensions:  4.17" long x 2.80" tall x 1.0" deep
Mounting:  Surface mounting holes; 4.625" center-to-center
Power Supply:  115V AC

Documents


 Brochure



Video
