Habasit Flexproof Finger Cutter 60mm (6 x 30mm fingers)
Press and move to zoom.
Mouse over image to zoom.

Habasit Flexproof Finger Cutter 60mm (6 x 30mm fingers)

Part Number: AF-61/6X30

The AF-61/6x30 is a preparing device (die-cutting tool) for 6x30 mm Flexproof finger geometry. It is designed mainly for Habasit machine tapes and belts up to 3 mm thickness. The AF-61/6x30 has a movable cutting head with two blades. It can be positioned by a pin in steps of 6 mm, ensuring the required accuracy. The fingers are thus cut manually step by step by means of a lever. The AF-61/6x30 is designed and suitable for occasional on-site preparation of Hamid tapes and belts.

$2,635.77 /EACH
List price: $2,635.77 /EACH
    • EACH
  • Availability: Call for availability
Technical Data
Belt/Tape Max Width:  60mm (2.36 in.)
Belt/Tape Max Thickness:  3mm (0.12 in.)
Weight: 4.2 kg (9.25 lb)
Dimensions: 180 x 150 x 170mm (7 x 5.9 x 6.7 in.)
