StitchMaster115VAC/60Hz, with G8 Head - High Performance Series
Double-tap and hold to zoom.
Mouse over the image to zoom.

StitchMaster115VAC/60Hz, with G8 Head - High Performance Series

Part Number: SMHP-A25G8

The StitchMaster HP is the Graphic Arts Industry’s premier, portable, high-quality stitcher. It is quiet, fast and very dependable, in addition to being affordable. The StitchMaster HP is constructed in such a way that two machines may be mounted side-by-side to effectively create a dual-head stitcher at a cost considerably less than that of traditional multi-head stitchers.

It accommodates both Flat and Saddle stitching. The machine also has a rear contact trip and a foot switch for easy operation and single or continuous stitch modes can be accomplished at the touch of a button. Clamp it either to your own work table or to a heavy duty floor stand, which adjusts vertically from 28” to 42”. Floor stand sold separately.

$5,060.00 /EACH
List price: $5,060.00 /EACH
    • EACH
  • Availability: Available to Order


Technical Data
Model: StitchMaster 115 HP Series
Capacity: 2 sheets up to 1/4"
Crown Size: 1/2"
Wire Sizes: 25 gauge round
Throat Depth: 9" for saddle and 5" for flat or horizontal
Clinch: Flat Stitching and Saddle Stitching
Electrical: 115 VAC, 60 Hz
Dimensions: 24" H x 16" W x 15" L
Shipping Weight: 55 lbs



Operation Manual
