Akiles
• Protective safety cover keeps your fingers safely out of the cutting area during use.
• Patented upper die design & micro-adjustable lower die, allow for smooth and accurate cuts.
• Switch between automatic foot pedal or manual hand operation with the flip of a switch.
• Separate built-in storage bins for tools and corner scraps.
• Large Work Table
• Heavy-Duty Foot Pedal
| Technical Data | |
|---|---|
| Model: | Diamond-6 |
| Operation: | Electric |
| Maximum Capacity: | 2-3/8" (60mm) - 600 sheets (20 lb.) |
| Available Dies: | 1/8", 1/4", 3/8", 1/2", 5/8", Straight and Slot |
| Included Knife/Die: | 1/4" |
| Cutting Speed: | 46 RPM |
| Motor: | 100 W |
| Electrical: | 110 VAC, 60Hz |
| Dimensions: | 24-5/8" W x 12-5/8" L x 17-1/2" H |
| Weight: | 104 lbs. |
| Warranty: | 1 year |
| Model Name | Akiles Diamond-5 | Akiles Diamond-6 | Akiles Diamond-7 | Lassco Wizer CR-50XP | Challenge SCM |
|---|---|---|---|---|---|
| Model: |  |  |  |  |  |
| Max Capacity: | 2" | 2-3/8" | 2-3/4" | 1/2" | 4" |
| Operation: | Electric | Electric | Electric | Pneumatic | Hydraulic |
| Table Size: | 10" x 11.5" | 11.75" x 12.5" | 11.75" x 12.5" | 17" x 17" | 20.25" x 24" |
| Radius Sizes: | 1/8" to 3/8" (3 Options) | 1/8" to 5/8" (7 Options) | 1/8" to 5/8" (7 Options) | 1/16" to 1.5" (12 Options) | 1/8" to 5/8" (6 Options) |
| Weight: | 55 lbs. | 104 lbs. | 110 lbs. | 73 lbs. | 190 lbs. |
| Knife Included: | (1) 1/4" and (1) 1/8" | (1) 1/4" Knife | (1) 1/4" Knife | Sold Separately | (1) Knife & Die Set |
| 45° Straight Cut | Not Available | Available | Available | Not Available | Available |
| Electrical | 110V, 50/60Hz, 60W | 110V, 50/60Hz, 100W | 110V, 50/60Hz, 200W | N/A | 1Ph, 115V, 60Hz |
Need equipment for smaller production environments? Consider Manual Corner Rounders.
