Meech Hyperion Mid-Range Pulsed DC Ionizing Bar 800mm (31.5" overall)

Mouse over the image to zoom. Double-tap and hold to zoom.

Meech Hyperion Mid-Range Pulsed DC Ionizing Bar 800mm (31.5" overall)

Name: Meech Hyperion Mid-Range Pulsed DC Ionizing Bar 800mm (31.5" overall)
Brand: Meech
SKU: 945IPS-31
Price: 1515.00 USD
Availability: InStock

Part Number: 945IPS-31

The Hyperion 945IPS is a compact pulsed DC ionizing bar. It is used to control static electric charges in mid range applications from 150-600mm (6" - 24"). An integral 15kV pulsed DC power supply allows for easy installation on printing, converting and packaging machinery. Requiring only a 24V DC supply, the 945IPS removes the need to route high-voltage cabling through the machine.

Power Cord sold separately (options).

$1,515.00 /EACH

Qty

EACH

Online Availability

Available to Order

Description Product Reviews

Complete System:

- 924IPS Ionizing Bar

- 100-240V AC Power Cable or PLC/Direct Connect 24V Power Cable

Specifications

Technical Data
Typical Operating Range:	5.90" (150mm) - 23.62" (600mm)
Dimensions:	1.18" (30mm) x 2.64" (67mm)
Max Length:	155.91" (3960mm)
Weight:	1.98 lb (0.9 kg) / meter
Mounting:	'T' slot with M4 x 35mm studs
Input Voltage & Current:	24 V DC Max 625mA
Output Voltage:	Adjustable, +/- up to 15kV pulsed DC
Electrical Connection:	4 Pole M8
Output Frequency:	Default: 5 Hz (adjustable with BarMaster)
Output Balance:	Default: 52% positive, 42% negative
Max Ambient Temp:	60° C (140° F)
