XVT-2213 Polyamide Folder-Gluer Belt 1/2"

Part Number: XVT-2213-1/2

Main Industry Segments: Cardboard converting, Paper manufacturing and processing

Applications: Folder-gluer belt, processing belt

Special Features: Abrasion resistant, adhesive-free joint, constant coefficient of friction, dimensionally stable, forgiving in case of short term shock-like overloads

DISCONTINUED PRODUCT

This belting material has been discontinued by the manufacturer and replaced by CM-4/40F.

Contact us for pricing

XVT-2213 Polyamide Folder-Gluer Belt 3/4"

XVT-2213 Polyamide Folder-Gluer Belt 1"

XVT-2213 Polyamide Folder-Gluer Belt 1-1/4"

XVT-2213 Polyamide Folder-Gluer Belt 1-1/2"

XVT-2213 Polyamide Folder-Gluer Belt 1-3/4"

XVT-2213 Polyamide Folder-Gluer Belt 2"

Belting Thickness (mm) 4.00mm
Belting Joining Method Flexproof

Online Availability

Discontinued

This item is no longer supplied by the manufacturer. Check the product page for alternatives or contact us to explore possible substitutes.

Description Product Reviews

Specifications

Product Construction
Conveying Side Material:	Acrylonitrile-Butadiene-Rubber (NBR)
Conveying Side Surface:	Rough Structure
Conveying Side Property:	Adhesive
Conveying Side Color:	Light Green
Traction Layer:	Polyamide
Number of Fabrics:	2
Pulley Side Material:	Acrylonitrile-Butadiene-Rubber (NBR)
Pulley Side Surface:	Rough Structure
Pulley Side Property:	Adhesive
Pulley Side Color:	Yellow

Product Data
Joining Method:	Flexproof
Belt Thickness:	4.00mm (0.16 in)
Tensile Force (1% elongation/unit of width):	7 N/mm (40 lbf/in)
Min. Operating Temp:	-20°C (-4°F)
Max Operating Temp:	65°C (149°F)
Min Pulley Diameter:	50mm (1.97 in)
