• Commercial Grade 6 Roller Laminator with 2 Programmable Memory Settings
• Programmable Memory Settings: Allows you to save the ideal temperature and speed for your most frequent projects.
• 6 Roller Heat System: The 4 heated rollers + 2 cold rollers guarantee professional grade results and crystal clear lamination.
• Auto Shutoff: Automatically cools and shuts down the machine after usage, to prolong the life of your laminator.
• 13" and 18.9" Capacities: The large 13" (X6 / X10) or extra large 18.9" (XL) throat allows the machine to laminate a wide array of pouch sizes.
• Removable Cover: Allows quick access to the roller with easy-to-remove thumb screws.
• LCD Control Panel: Backlit LCD display with labeled keypad makes it easy to operate.
• Setting Guide: Shows the recommend temperature and speed settings for different pouch thicknesses.
• Air Cooling System: Patented internal cooling system ensures the laminator stays cool to the touch while in use.
| Technical Data | |
|---|---|
| Application: | Commercial Medium-Duty |
| Model: | ProLam Photo |
| Throat Capacity: | 13" (330mm) |
| Motor: | DC 12V / 1150W |
| Laminating Heat Range: | 32 - 320° F |
| Max Pouch Thickness: | 10 mils ( 250 mic.) |
| Max Laminating Thickness: | 1mm |
| Temperature Control: | Electronic (8-bit Micro Processor) |
| Laminating Speed: | Variable (12" - 59"/min) |
| Cover: | Metal |
| Weight: | 39 lbs |
| Warranty: | One Year |
 |  |
| Brochure | Operation Manual |
| Model Name | ProLam 160 | ProLam 330 | iLam Plus | ProLam Photo | ProLam Ultra | ProLam Ultra-X6 | ProLam Ultra-XL | ProLam Ultra-X10 | ProLam R27 |
|---|---|---|---|---|---|---|---|---|---|
| Model: |  |  |  |  |  |  |  |  |  |
| Width Capacity: | 6.3" (160mm) | 13" (330mm) | 12.8" (325mm) | 13" (330mm) | 13" (330mm) | 13" (330mm) | 18.9" (480mm) | 13" (330mm) | 27" (685mm) |
| Max Laminating Speed: | 21" / minute | 21" / minute | 21" / minute | 59" / minute | 53" / minute | 59" / minute | 47" / minute | 142" / minute | 43" / Minute |
| Pouch/Film Thickness: | 3 to 10 mil | 3 to 10 mil | 3 to 10 mil | 3 to 10 mil | 3 to 14 mil | 3 to 14 mil | 3 to 14 mil | 3 to 14 mil | 1.5 to 10 mil |
| Max Laminating Thickness: | 1mm | 1mm | 1mm | 1mm | 3mm | 3mm | 3mm | 3mm | 3mm |
| Heated Rollers: | 2 Hot / 2 Cold | 2 Hot / 2 Cold | 2 Hot / 2 Cold | 4 Hot / 2 Cold | 4 Hot / 2 Cold | 4 Hot / 2 Cold | 4 Hot / 2 Cold | 6 Hot / 4 Cold | 2 Hot |
| Speed Control: | 1 Setting | 1 Setting | 1 Setting | 9 Settings | 9 Settings | 9 Settings | 9 Settings | 9 Settings | 9 Settings |
| Reverse Switch: | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Weight: | 14 lbs. | 20 lbs. | 15 lbs. | 39 lbs. | 33 lbs. | 35 lbs. | 44 lbs. | 57 lbs. | 93 lbs. |
